Western blot (WB): | 1:500-2000 |
Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-400 |
Figure 1. Western blot analysis of anti-NOX4 antibody (A00403). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human 293T whole cell lysates,
Lane 2: human U87 whole cell lysates,
Lane 3: human SH-SY5Y whole cell lysates,
Lane 4: human U251 whole cell lysates,
Lane 5: human U2OS whole cell lysates,
Lane 6: human Hela whole cell lysates,
Lane 7: human T47D whole cell lysates,
Lane 8: monkey COS-7 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-NOX4 antigen affinity purified polyclonal antibody (A00403) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for NOX4 at approximately 65 kDa. The expected band size for NOX4 is at 67 kDa.
Figure 2. IF analysis of NOX4 using anti-NOX4 antibody (A00403).
NOX4 was detected in an immunocytochemical section of U2OS cells. DyLight®488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).
Figure 1. Western blot analysis of anti-NOX4 antibody (A00403). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human 293T whole cell lysates,
Lane 2: human U87 whole cell lysates,
Lane 3: human SH-SY5Y whole cell lysates,
Lane 4: human U251 whole cell lysates,
Lane 5: human U2OS whole cell lysates,
Lane 6: human Hela whole cell lysates,
Lane 7: human T47D whole cell lysates,
Lane 8: monkey COS-7 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-NOX4 antigen affinity purified polyclonal antibody (A00403) and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for NOX4 at approximately 65 kDa. The expected band size for NOX4 is at 67 kDa.
Figure 2. IF analysis of NOX4 using anti-NOX4 antibody (A00403).
NOX4 was detected in an immunocytochemical section of U2OS cells. DyLight®488 Conjugated Goat Anti-Rabbit IgG (Green) (Catalog # BA1127) was used as secondary antibody. The section was counterstained with DAPI (Catalog # AR1176) (Blue).
