Western blot (WB): | 1:500-2000 |
Immunohistochemistry (IHC): | 1:50-400 |
Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-400 |
Enzyme linked immunosorbent assay (ELISA): | 1:100-1000 |
(Boiling the paraffin sections in 10mM citrate buffer,pH6.0,or PH8.0 EDTA repair liquid for 20 mins is required for the staining of formalin/paraffin sections.) Optimal working dilutions must be determined by end user. |
Figure 1. Western blot analysis of anti- CD45/PTPRC Antibody (A00555-4). The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: mouse spleen tissue lysates,
Lane 2: mouse thymus tissue lysates.
Use rabbit anti- PTPRC 1:1000, probed with a goat anti-rabbit IgG-HRP secondary antibody. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002). A specific band was detected for PTPRC at approximately 220KD. The expected band size for PTPRC is at 145KD.
Figure 2. IHC analysis using anti- CD45/PTPRC Antibody (A00555-4). detected in paraffin-embedded section of rat Lymph node tissue. Biotinylated goat anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 3. IHC analysis using anti- CD45/PTPRC Antibody (A00555-4). detected in paraffin-embedded section of rat spleen tissue. Biotinylated goat anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 4. IHC analysis using anti- CD45/PTPRC Antibody (A00555-4). detected in paraffin-embedded section of mouse Lymph node tissue. Biotinylated goat anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 5. ICC analysis using anti- CD45/PTPRC Antibody (A00555-4). was detected in immersion fixed RAW264.7 cell line. Cells were stained using the Dylight488-conjugated Anti-rabbit IgG Secondary Antibody (green)(Catalog#BA1127) and counterstained with DAPI (blue).
Figure 1. Western blot analysis of anti- CD45/PTPRC Antibody (A00555-4). The sample well of each lane was loaded with 50ug of sample under reducing conditions.
Lane 1: mouse spleen tissue lysates,
Lane 2: mouse thymus tissue lysates.
Use rabbit anti- PTPRC 1:1000, probed with a goat anti-rabbit IgG-HRP secondary antibody. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002). A specific band was detected for PTPRC at approximately 220KD. The expected band size for PTPRC is at 145KD.
Figure 2. IHC analysis using anti- CD45/PTPRC Antibody (A00555-4). detected in paraffin-embedded section of rat Lymph node tissue. Biotinylated goat anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 3. IHC analysis using anti- CD45/PTPRC Antibody (A00555-4). detected in paraffin-embedded section of rat spleen tissue. Biotinylated goat anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 4. IHC analysis using anti- CD45/PTPRC Antibody (A00555-4). detected in paraffin-embedded section of mouse Lymph node tissue. Biotinylated goat anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 5. ICC analysis using anti- CD45/PTPRC Antibody (A00555-4). was detected in immersion fixed RAW264.7 cell line. Cells were stained using the Dylight488-conjugated Anti-rabbit IgG Secondary Antibody (green)(Catalog#BA1127) and counterstained with DAPI (blue).
