Western blot (WB): | 1:500-2000 |
Immunohistochemistry (IHC): | 1:50-400 |
Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-400 |
Immunofluorescence (IF): | 1:50-400 |
(Boiling the paraffin sections in 10mM citrate buffer,pH6.0,or PH8.0 EDTA repair liquid for 20 mins is required for the staining of formalin/paraffin sections.) Optimal working dilutions must be determined by end user. |
Figure 1. Western blot analysis of Anti-PTPRC antibody (BA3371). The sample well of each lane was loaded with 50ug of sample under reducing conditions.Lane 1: JURKAT whole cell lysates,Lane 2: CEM whole cell lysates,Use rabbit Anti-PTPRC 1:1000, probed with a goat Anti-rabbit IgG-HRP secondary antibody. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002). A specific band was detected for PTPRC at approximately 147KD. The expected band size for PTPRC is at 147KD.
Figure 2. IHC analysis using Anti-PTPRC antibody (BA3371) detected in paraffin-embedded section of human tonsil tissue. Biotinylated goat Anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 3. IHC analysis using Anti-PTPRC antibody (BA3371) detected in paraffin-embedded section of JURKAT cell. Biotinylated goat Anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 4. IF analysis using Anti-PTPRC antibody (BA3371) detected in paraffin-embedded section of human tonsil tissues. The tissue section were stained using the Dylight488 conjugated Anti-rabbit IgG Secondary Antibody (green)(Catalog?#?BA1127) and counterstained with DAPI (blue).
Figure 1. Western blot analysis of Anti-PTPRC antibody (BA3371). The sample well of each lane was loaded with 50ug of sample under reducing conditions.Lane 1: JURKAT whole cell lysates,Lane 2: CEM whole cell lysates,Use rabbit Anti-PTPRC 1:1000, probed with a goat Anti-rabbit IgG-HRP secondary antibody. The signal is developed using an Enhanced Chemiluminescent detection (ECL) kit (Catalog # EK1002). A specific band was detected for PTPRC at approximately 147KD. The expected band size for PTPRC is at 147KD.
Figure 2. IHC analysis using Anti-PTPRC antibody (BA3371) detected in paraffin-embedded section of human tonsil tissue. Biotinylated goat Anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 3. IHC analysis using Anti-PTPRC antibody (BA3371) detected in paraffin-embedded section of JURKAT cell. Biotinylated goat Anti-rabbit IgG was used as secondary antibody. The tissue section was developed using Strepavidin-Biotin-Complex (SABC) (Catalog # SA1022) with DAB as the chromogen.
Figure 4. IF analysis using Anti-PTPRC antibody (BA3371) detected in paraffin-embedded section of human tonsil tissues. The tissue section were stained using the Dylight488 conjugated Anti-rabbit IgG Secondary Antibody (green)(Catalog?#?BA1127) and counterstained with DAPI (blue).
